Yas sealing thiab txiav tshuab
Lub Zog: 5KW 8KW 12KW
Voltage: 220V/380V 50/60Hz 220V/380V 50/60Hz 220V/380V 50/60Hz
Zaus: 27.12MHz 27.12MHz 27.12MHz
Lub zog hluav taws xob: 10KVA 15KVA 22KVA
Xa kev nug
Product Details ofYas sealing thiab txiav tshuab
Khoom Taw Qhia
Thaum tsim cov hlwv - daim npav ntim rau cov khoom siv kho vajtse lossis cov hnab PU me me, phau ntawv kauj ruam -los ntawm - cov kauj ruam ua haujlwm ntawm kev pub mis, vuam thiab txiav yog qeeb thiab yuam kev- nquag. Nyias PE zaj duab xis feem ntau tawg thiab nkim, thiab cov cuab yeej sib txawv yog xav tau rau ntau- cov khoom siv. Lub tshuab yas sealing thiab txiav tshuab no siv lub tshuab tig tsis siv neeg tag nrho, nrog rau tag nrho cov txheej txheem los ntawm kev pub noj kom tau txais yam tsis muaj kev cuam tshuam. Nws ua tiav vuam thiab sealing & txiav synchronously, thiab cov ntaub ntawv nyias tsis yooj yim rau kev puas tsuaj. Nws tuaj yeem hloov kho rau cov ntaub ntawv xws li PVC, APET thiab PU, thiab tuaj yeem ua haujlwm zoo me me -batch thiab ntau- pawg yas sealing & txiav txiav.
Khoom nta
Kev Ua Haujlwm Tsis Muaj Neeg Ua Haujlwm Ua Haujlwm: Sib koom ua ke pub noj tsis siv neeg, siab - zaus vuam, synchronous sealing & txiav thiab ua tiav cov khoom tau txais kev ua haujlwm. Tsis muaj kev cuam tshuam los ntawm phau ntawv hauv kev sib txuas nruab nrab-ib tus neeg tuaj yeem ua haujlwm cov khoom siv, txo cov nqi zog ntau dua 60%.
Precise Compatibility nrog ntau yam ntaub ntawv:Core- sib xws nrog PVC thiab APET feem ntau siv hauv blister - daim npav ntim khoom, thiab tseem txhawb nqa PU, TPU thiab nyias PE zaj duab xis sib xyaw ua ke tsawg dua lossis sib npaug li 0.15mm. Nws tuaj yeem ua haujlwm ruaj khov rau ob qho tib si kev lag luam - qib kho vajtse ntim thiab zaub mov- qib nyias zaj duab xis sealing & txiav.
Cov khoom nyias nyias los tiv thaiv -Tso tsis muaj pov tseg:Optimizes zog tso zis nkhaus rau nyias PE, APET thiab lwm yam yooj yim - mus rau - cov ntaub ntawv tawg, ua ke nrog millisecond - qib spark detection, zam cov khoom burnout thiab seem, thiab zoo heev txhim kho tus nqi yield.
Synchronous Sealing & Txiav Txuag Cov Txheej Txheem:Ua tiav ntug txiav thaum vuam, nrog zoo huv si thiab burr -dawb tiav cov npoo, tsis tas yuav tsum tau trimming. Nws yog 40% ntau dua li cov khoom siv ib txwm siv thiab tuaj yeem ua kom muaj qhov ntim zoo ib yam.
Khoom Parameters
|
Yam khoom |
YJ-HF-5KW |
YJ-HF-8KW |
YJ-HF-12KW |
|
Hwj chim |
5 kWm |
8 kWm |
12 kWm |
|
Qhov hluav taws xob |
220V / 380V 50 / 60Hz |
220V / 380V 50 / 60Hz |
220V / 380V 50 / 60Hz |
|
Ntau zaus |
27.12 MHz |
27.12 MHz |
27.12 MHz |
|
Lub zog nkag |
10 KVA |
15 KVA |
22 kVA |
|
Rectifier |
Silicon Diode |
Silicon Diode |
Silicon Diode |
|
Electron Tube |
7t62 wb |
7t69 wb |
8t85 wb |
|
Siab |
300 KG |
500 KG |
800 KG |
|
Lub sijhawm |
110 MM |
140 MM |
170 MM ib |
|
Inner Size |
9 0MM |
110 MM |
130 MM |
|
Upper Size |
150 × 150 hli |
200 × 200 hli |
250 × 250 hli |
|
Qhov Loj |
150 × 150 hli |
200 × 200 hli |
250 × 250 hli |
|
Lub sijhawm vuam |
0.2-5S (Adjustable) |
0.2-5S (Adjustable) |
0.2-5S (Adjustable) |
Qhov chaw nthuav dav nplooj duab
Core Application Scenarios
Kev tsim khoom loj ntawm Blister-Daim npav ntim rau cov khoom siv kho vajtse:Hardware accessory ntim yuav tsum muaj kev sib txuas ruaj khov ntawm blister thiab daim npav. Kev tuav cov txheej txheem tsis muaj txiaj ntsig nrog cov npoo tsis sib xws. Cov cuab yeej no paub txog qhov tsis siv neeg synchronous sealing & txiav nrog qhov tseeb qhov chaw, sealing & txiav yuam kev Tsawg dua lossis sib npaug li 0.5 hli. Cov npoo tiav yog burr-dawb yam tsis muaj kev ua haujlwm thib ob. Kev ua haujlwm loj ntau yog 5 zaug sai dua li kev ua haujlwm ntawm phau ntawv, thiab zam cov khoom pov tseg.
Sealing & txiav ua cov khoom me me PU / TPU:PU cov hnab nyiaj hniav nyiaj hniav kub thiab TPU cov khoom siv niaj hnub xav tau kev sib khi ruaj khov, thiab cov khoom siv nyias nyias yuav ua rau tawg. Cov khoom siv nyias cov khoom siv los tiv thaiv - kev ua haujlwm tawg ua kom lub zog tso tawm, ua kom nruj thiab xau- pov thawj sealing. Synchronous sealing & txiav yog ua tiav nyob rau hauv ib kauj ruam, hloov mus rau me me -batch thiab ntau-style customized txiav txim. Cov khoom sib txawv tuaj yeem ua tiav yam tsis hloov khoom siv.
FAQ
1.Rau cov hlwv - daim npav ntim, tuaj yeem vuam ntawm daim npav thiab blister thiab ntug txiav ua tiav ib txhij?
A: Yog. Cov cuab yeej siv synchronous sealing & txiav pwm, ua kom tiav ntug txiav thaum vuam daim ntawv thiab hlwv hauv ib kauj ruam. Cov npoo tiav yog huv si yam tsis muaj trimming ntxiv.
2.Yuav 0.1mm nyias PE zaj duab xis puas yuav tawg los yog tsis muaj zog sealing thaum txiav?
A: Tsis yog. Cov khoom siv optimizes lub zog tso zis rau nyias PE zaj duab xis, ua ke nrog kev tiv thaiv kev tiv thaiv, uas yuav tsis ua rau cov khoom tawg. Lub foob yog tshwj xeeb yog ruaj, tsis muaj cracking los yog huab cua to.
3.Kuv puas yuav tsum tau kho ntau yam tsis zoo thaum hloov ntawm PVC thiab PU cov ntaub ntawv rau kev ua haujlwm?
A: Tsis yog. Cov cuab yeej muaj ib qho ua tau - nyob rau hauv lub tsev qiv ntawv parameter rau cov khoom siv. Xaiv cov khoom siv los txiav txim siab lub zog thiab siab. Kev ua haujlwm yog yooj yim, thiab cov novices tuaj yeem pib sai.
4.Yuav ua li cas yog electromagnetic shielding nyhuv ntawm cov khoom? Nws puas ua tau raws li cov qauv kev nyab xeeb?
A: Yog. Cov ntaub thaiv npog tag nrho cov khoom siv hluav taws xob tiv thaiv hluav taws xob tuaj yeem thaiv qhov siab - hluav taws xob zaus, nrog rau cov hluav taws xob hluav taws xob qis dua li cov qauv kev nyab xeeb thoob ntiaj teb. Nws yog tag nrho raws li kev cob qhia siv thiab tsis cuam tshuam rau kev noj qab haus huv ntawm cov neeg ua haujlwm.
5. Puas yog nws nyuaj los hloov cov pwm pwm ntawm qhov sib txawv? Nws siv sijhawm ntev npaum li cas?
A: Tsis yog, nws tsis nyuaj. Ib tus kws tshaj lij tuaj yeem hloov nws hauv 5 feeb. Cov pwm yog ceev -tso tawm tsim, tsis muaj cov cuab yeej tshwj xeeb xav tau. Teem lub interface thiab xauv nws, tom qab ntawd hu rau cov tsis sib xws los pib tsim khoom.
6.Cov khoom puas tuaj yeem txuas rau lub tshuab pub mis tsis siv neeg kom ua tiav cov khoom siv tsis siv neeg?
A: Yog. Nws khaws cia qhov kev pub noj tsis siv neeg, uas tuaj yeem txuas mus rau cov khoom siv pub mis tsis siv neeg rau cov hlwv thiab daim ntawv daim ntawv, ua kom tiav tag nrho cov khoom siv tsis siv neeg los ntawm kev pub noj kom tau txais, ntxiv kev txhim kho kev tsim khoom loj.
